Description
INVERTER OUTPUT [AC]
| Rated Power | 5000W |
| AC Voltage Regulation (Battery) | 230VAC ± 5% |
| Surge Power | 10000VA |
| Efficiency (Peak) | 93% |
| Waveform | Pure sine wave |
| Transfer Time | 10ms ~ 20ms |
SOLAR CHARGER
| Maximum PV Array Power | 4500W |
| MPPT Range @ Operating Voltage | 60 VDC ~ 115 VDC |
| Maximum PV Array Open Circuit Voltage | 145VDC |
| Maximum Solar Charge Current | 80A |
| Maximum Efficiency | 97% |
AC CHARGER
| AC Charge Current | 60A |
| AC Input Voltage | 230 VAC |
| Selectable Voltage Range | 90 - 280 VAC |
| Frequency Range | 50 Hz/60 Hz (Auto sensing) |
BATTERY
| Battery Voltage | 48 VDC |
| Battery Type(s) | Lithium / Lead-acid |
| Floating Charge Voltage | 54 VDC |
| Overcharge Protection | 66 VDC |
DIMENSIONS & WEIGHT
| Height | 455mm |
| Width | 350mm |
| Depth | 130mm |
| Weight | 11.5 kg |
