Lithium battery 200Ah 12v (2.4kWh) - VC12200

Product Summary

Name: Lithium Battery 200 Ah 12 V – Model VC12200
Type: High-capacity LiFePO₄ (Lithium Iron Phosphate) deep-cycle battery (≈ 2.4 kWh)

Brief Description

The VC12200 is a rugged, OEM-grade 12 V 200 Ah lithium battery, ideal for solar backup, off-grid power, telecom, RVs, marine, and generator battery banks. It features a built-in BMS for cell safety, Bluetooth for remote monitoring, and robust ABS housing for durability.

Performance Highlights

• Recommended Charge Current: 50 A (max 100 A)

• Continuous Discharge: 100 A (peak 400 A, short bursts)


• Operating Temps: 0–55 °C charge; –20–60 °C discharge (LiFePO₄ standard)


• Ingress Protection: IP65 enclosure

• Cycle Life: ~4,000 cycles to 80% depth of discharge

Key Specifications

• Voltage: 12.8 V nominal

• Capacity: 200 Ah (≈ 2,560 Wh energy storage; 2.2 kWh usable)


• Chemistry: LiFePO₄ with integrated BMS and Bluetooth monitoring


• Dimensions (L×W×H): 520 × 270 × 220 mm


• Weight: 31.5 kg
